Free fishing rig diagrams by species.

Pick your fishing region, where you're fishing, and what you're targeting. Get the best rig, tackle sizes, bait guidance, and a matched rod in seconds.

36
Rig diagrams
152
Fish species
6+
Countries
Angler holding a catch on the beach with popular target species
Interactive Rig Matcher
Find the right rig, fast.
Surf · pier · jetty · boat · kayak · river · lake
What you get
Exact measurements
Clear diagrams
Matched tackle
Interactive rig matcher

Where are you fishing?

Start with your location. Add a target species only if you know what you're after.

1Location2Species
Fishing region
Global / Anywhere · US / Imperial
Step 2 · Optional

What are you targeting?

Your setup

Best match for pier fishing

Matched from your location. Start here, then compare the alternatives below.

Live match updated
#1 Best Matchbeginner

High-Low Rig

Two hooks sit above a bottom weight so bait hovers just off the sand. Simple to tie and easy to re-rig on the beach, which makes it the standard starting point for surf and pier fishing.

Main line
12-15 lb monofilament
Leader
15 lb fluorocarbon
Hooks
#4 - #2 baitholder
Weight
Pyramid sinker, 2-4oz
Leader length
8in from main line to each hook
Sinker drop
4-6in from bottom swivel to sinker
High-Low surf fishing rig visual guide showing line, swivels, hooks, sinker, bait, target species, and recommended tackleView full visual guide →
Global fishing conditions

Wind, waves, swell & light timing.

Global mode uses worldwide marine and weather data. Detailed tide curves currently use NOAA stations in the United States; outside the US, RigMyFish shows the conditions it can verify globally instead of inventing tide predictions.

Open-Meteo global data
Choose a coastal location

See wind, waves, swell, sea temperature when available, and sunrise/sunset. Tide predictions are shown only when a verified tide provider is available.

Planning information only, not a marine-safety forecast or guarantee of fish activity.
Backup options

Also works well

All rigs →
Realistic Fish-Finder Rig fishing rig setup
Fish-Finder Rig
The sinker slides freely on the main line, so a fish can pick up bait and move off without feeling resistance.
View rig →
Realistic Fireball Rig fishing rig setup
Fireball Rig
A high-low rig with a bright float threaded above the hook, lifting bait slightly off the bottom and adding visibility in murky surf.
View rig →
Realistic Freeline Rig fishing rig setup
Freeline Rig
No weight at all, just a hook tied straight to the line.
View rig →
Realistic Slip Bobber Rig fishing rig setup
Slip Bobber Rig
A bobber that slides freely on the line until it hits an adjustable stop knot, letting you fish any depth while still casting easily.
View rig →
Realistic Sabiki Rig fishing rig setup
Sabiki Rig
A pre-tied string of small flasher hooks that catches live bait like anchovies and sardines, often several at once.
View rig →
Braid or light monoLeader knotLeaderJig head 1/16 - 1/2ozHook point upSoft plastic grub
Light Jig Head Rig
A small lead jig head threaded with a soft plastic grub or paddle-tail, cast out, allowed to sink, and lifted and dropped back toward the bottom.
View rig →
Main lineCupped corkWire, clacker beadsSurfaceLeader 18-36inLive shrimp
Popping Cork Rig
A fixed cork with a cupped face threaded on a stiff wire with rattling beads.
View rig →
Main lineLeader3-5 linked hooksthrough a whole pilchard or garfish
Ganged Hook Rig
Three to five hooks are linked in a chain, each point passing through the eye of the next, and the whole gang runs the length of a pilchard or garfish.
View rig →
Realistic Float Rig fishing rig setup
Float Rig
A float suspends bait at a fixed depth instead of dragging it on the bottom, letting current or light wave action carry it naturally past holding fish.
View rig →
Realistic Wire Leader Rig fishing rig setup
Wire Leader Rig
Swaps the usual fluorocarbon leader for wire, since sharp teeth cut straight through mono.
View rig →
Main linePulley swivel slidesalong the rig bodyRig body 60-80 lbSnood swivelHook snoodBait clipped downGrip lead
Pulley Rig
The main line is tied to a swivel that slides along a short, heavy rig body with the lead at one end and the hook snood at the other.
View rig →
Main line 20-30 lbSwivelHook snoodWeak link, 6-10 lbbreaks before the main lineOld weightRock and kelp
Rotten-Bottom Rig
The weight is tied on with a short piece of much lighter line, so if it jams in a crevice you pull, the weak link snaps, and you keep the rig and the fish.
View rig →
Main lineSmall swivelWire leaderLead hook in noseTreble stingerLive bait, slow-trolled
King Mackerel Stinger Rig
A lead hook goes through the nose of a live bait and a small treble on a short wire stinger trails back into its flank, because king mackerel attack the tail and slice baits in half.
View rig →
Heavy main lineSwivel or wind-onLeader60-200 lbCircle hookLive bait, floss bridlethrough the nose or eye sockets
Heavy Live Bait Rig
A big non-offset circle hook is bridled through the nose or eye sockets of a live mackerel, scad, or small tuna with floss, so the bait swims freely and the hook stays clear to set in the corner of the jaw.
View rig →
PierAnchor lineGrapnel sinkerFighting lineTrolley clipLive bait
Pier Trolley Rig
A heavy grapnel sinker is cast from the end of a pier on one rod and the line pulled tight; a live bait on the fighting rod is then clipped to that anchor line and slides down it to swim near the surface far from the pilings.
View rig →
How RigMyFish works

Less guessing. More fishing.

The site is designed around the questions anglers actually ask at the beach, pier, dock, or tackle counter.

Why we built it →
01

Choose water

Surf, pier, jetty, boat, kayak, river, or lake.

02

Pick a species

Optional. Narrow the setup to the fish you're targeting.

03

Check the tide

For ocean trips, see the next 24–48 hours and stronger tide-movement windows.

04

Rig with confidence

Get exact line, leader, hook, sinker, bait, and rod guidance.

Popular guides

Learn why a rig fits the situation

The matcher gives you the fast answer. These deeper guides explain the conditions and tradeoffs behind it.

View all guides →
Built for trust

Transparent sources and review process

Season and regulation context is separated from practical rig guidance and linked to primary sources when applicable. Current regulations always take precedence over site summaries.

Quick answers

Common questions

Is RigMyFish free to use?

Yes. Every rig diagram, gear list, rod recommendation, knot guide, and bait page is free with no account, no app, and no ads to scroll past.

How does the rig matcher work?

Pick where you're fishing (surf, pier, jetty, boat, kayak, river, or lake) and optionally a target species. RigMyFish returns the best-matched rig with a diagram and exact gear list, a backup rig or two, and a recommended rod.

What region does RigMyFish cover?

RigMyFish covers species and rig guidance across the United States, Canada, United Kingdom, Ireland, Australia, and New Zealand, plus a global view. Country filters use local species coverage, regional rig names, and metric or imperial defaults.

Do the rigs include exact measurements?

Yes. Each rig lists the main line, leader material and length, hook size range, weight type and size, and the line-to-sinker distance, so you can tie it without guessing.
